SounDigital 800.1 EVO 5

The 800.1 EVO 5 is a compact, modern amplifier that delivers 800W RMS of power distributed over 1 channel.

The amplifier features exclusive and patented technologies that make the sound experience cleaner and more faithful, in addition to ensuring better performance and efficiency for the most daring projects.

           2Ohm                            4Ohm

Power @ 2Ω: 800W         Power @ 2Ω: N/A
Power @ 4Ω: 528W         Power @ 4Ω: 800W
Power @ 8Ω: 348W         Power @ 8Ω: 528W




Frequency Response: 10Hz ~ 20kHz

Subsonic Filter (HP 12dB/8º): 10Hz ~ 80Hz

Low Pass Filter (LP 12dB/8º): 50Hz ~ 20kHz

Operating Voltage: 8V ~ 16V

SNR: 4Ω: 97dB

Input Sensitivity (RCA): 0.2V ~ 4V

Input Sensitivity (High Level input): 1.5V ~ 15V

Current Draw (Music): 4Ω: 38A

Current Draw With Resistive Load (1kHz @ 12.6V): 4Ω: 77A

Total Efficiency: 4Ω: 78%

Damping Factor (@100Hz Rated Impedance): 200

Power Cable: 10mm² (7AWG)

Audio Output Cable: 2 x 2mm² (12 AWG)

Recommended Fuse (Music): 40A

Recommended Battery (Music): 60Ah

Width: 4.4 in / 11,3 cm

Length: 5.8 in / 14,8 cm

Height: 2 in / 5,1 cm

Weight: 1.54 lb / 0,7 Kg
